SKIPPER ECHO SOUNDERS DESCRIPTION DOWNLOADS
SKIPPER ESN200

The SKIPPER ESN200 is a navigation dual channel Echo Sounder with a black box and a 9" touch display. The Echo Sounder graphics are continuously shown on the screen along with complete navigational details. Most of the functions are automatic, but it is also possible to run it in manual mode.

  • Dual channel navigational echo sounder with 8 set frequencies: 24, 30, 33, 38, 50, 100, 200 and 210 kHz.
  • Posibilities for one or two transducers installed.
  • User friendly with automatic range, gain and power settings.



 Brochure
SKIPPER ESN100

The SKIPPER ESN100 is a navigation Echo Sounder with a black box and a 9" touch display. The Echo Sounder graphics are continuously shown on the screen along with complete navigational details. Most of the functions are automatic, but it is also possible to run it in manual mode.



  • Single channel navigational echo sounder.
  • Posibilities for one or two transducers installed.
  • User friendly with automatic range, gain and power settings.


Brochure

SKIPPER GDS101

The SKIPPER GDS 101 is a navigation Echo Sounder with a large, high resolution colour LCD display. The Echo Sounder graphics are continuously shown on the LCD along with complete navigational details. External connectors are provided for printer, VGA and NMEA in/output.



  • Single frequency 38, 50 or 200 kHz
  • Colour TFT LCD, with Day/night screen
  • Data in/outputs and - Analog outputs.
  • Possibility for external printer
  • Low and high frequency
  • More than 1 month depth recording depending on Compact Flash memory card


Brochure
SKIPPER GDS102

The SKIPPER GDS 102 is a dual channel navigation Echo Sounder with a large, high resolution colour LCD display. The Echo Sounder graphics are continuously shown on the LCD along with complete navigational details. External connectors are provided for printer, remote VGA and NMEA in/output.



  • Dual Channel Echo Sounder prepared for connection of 1 or 2 transducers with a resonant frequency in the range of 10-265 kHz
  • Colour TFT LCD, with Day/night screen
  • Data in/outputs and - Analog outputs
  • Possibility for external printer
  • Low and high frequency
  • More than 1 month depth recording depending on Compact Flash memory card





Brochure
